Sumoto Motor OY6 – 6 Inch

The OY6 oil-filled submersible motor is engineered for demanding water supply applications, offering robust performance and extended durability. Designed for use in 6-inch and larger diameter wells, it is an excellent choice for agricultural, industrial, and municipal water systems. Filled with high-quality, dielectric, non-toxic oil, this motor ensures safe operation in potable water applications while providing efficient cooling and superior insulation. The oil-filled design guarantees excellent thermal exchange, reducing operating temperatures and enhancing motor life. At Sumoto, we have been producing these reliable 6-inch oil-filled motors since 1996, continuously improving their design and performance to meet the highest standards of durability and efficiency.

The motor features a removable cable connector for quick and easy maintenance. Our flat blue power cable, approved for use with drinking water, is certified according to ACS, KTW, and WRAS. Upon request, a stranded cable version is also available.

The upper bracket can be supplied in various materials and finishes to suit different application requirements: a Standard version in nickel-plated cast iron, or entirely in stainless steel 304 or 316 for enhanced corrosion resistance.

The OY6 series features precision-engineered thrust and radial ball bearings, capable of handling high axial and radial loads. This confiquration quarantees reliable performance and long service life, even under harsh
conditions.

Description

Technical Information

• Rewindable.

• Upper bracket: Nickel plated cast iron. SS316 available.

• Motor case: SS 304. • Motor shaft: SS 304.

•Shaft extention and coupling: NEMA standard.

• High quality radial and thrust ball bearings.

•Winding: enameled copper – Class Finsulation.

• Degree of protection: IP68/Class B.

• Max temp. 35° with water cooling flow min. 0.16 m/s.

• Max depth immersion: 150 m.

• Nos. of start per hour: max 30 at regular intervals.

• Over-dimensioned sand slinger.

• Mechanical seal: graphite/ceramic. SiC/SiC or SiC/Al mechanical seal available as option.

• Coolant: dielectric non toxic high quality lubricant.

• Motor cable length: 2,8 to 4 m according to motor size (3 wires plus ground).

• Voltage variation: +/-10%.

• Starting method: D.O.L/ Star-Delta.

• CSCR single phase motor available.

• Suitable for horizontal operation.

Motor Range Versions

• Single Phase: 4kW (5.5hp) to 11kW (15hp), 220-230V/50Hz (or 60Hz)
• Three Phase: 4kW (5.5hp) to 37kW (50hp), 380-415V/50Hz – 460V/60Hz
• Axial thrust:
– 10.000 N from 4kW to 22kW
– 20.000 N from 30kW to 37kW.
